3 Phase 415V 4.5kw L-Shaped PTFE Immersion Heater for acid heating and corrosive chemical heating


Fluoropolymer (PTFE) heaters are an excellent choice for heating Aqueous acid, alkaline, anodizing and pickling solutions up to 212°F (100°C). The heater head (terminal enclosure) is available in Nema 4X compliant (consult factory) or vapor tight, corrosion resistant – flame retardant polypropylene, equipped with 3 foot (.9m) corrosion resistant thermoplastic flexible conduit.

This product offers thick gauge stainless steel tubular elements covered with heavy wall fluoropolymer (PTFE) reducing permeation, eliminating the need for gas purge systems. This product is an excellent choice for heating electroless chemistries – not for use in Chromic Acid. Please refer to our Immersion Heater Solution Guide in addition to your chemical supplier for recommended outer heater sheath material.

WHAT IS A PTFE HEATER?
A PTFE heater is a specialized immersion heater that has been sleaved with the highly resistant, beneficial plastic compound known as polytetrafluoroethylene – PTFE for short. PTFE is the most commonly used fluoropolymer and is the material used in the Teflon brand of products by DuPont. PTFE has numerous properties that make it highly sought after for applications that prioritize safety and dependability.

Miraculously, while it was discovered by accident in 1938, DuPont scientists quickly realized PTFE’s properties make it highly resistant to most acids, detergents and solvents. In addition, PTFE has a high melting point and an extreme amount of flexibility, making it ideal protection for immersion heaters that need to be immersed in corrosive and reactive chemicals in many industries. PTFE immersion heaters are sleaved in the PTFE compound, so the metal underneath is not subjected to the corrosive solutions they heat. Using an immersion heater sleaved with PTFE can allow you to heat chemicals rated up to 13 pH. With this particular compound, your immersion heater can spend as much time submerged in corrosive chemical solutions as necessary.

PTFE heaters offer extreme durability against corrosive solutions, but careful practice must be taken when using them. PTFE is a soft material and vulnerable to nicks, cuts or abrasions that could leave the underlying heating element exposed to corrosion. Polypropylene guards can protect the PTFE-sleaved components from damage.

While PTFE is the most versatile plastic in terms of chemical compatibility, it is not compatible with hydrochloric acid.
If you need to heat hydrochloric acid, ask us about our titanium heaters.


What is a teflon heater?
PTFE (Teflon) Heaters
Where conventional metal-clad heating elements aren't strong enough to do the job, PTFE heaters can provide clean, non-stick thermal transfer designed to withstand tough applications such as acid baths, medical equipment and commercial appliances.

FAQ
Q: Where is Surplus located?
A: Our office located in HongKong,Dongguan and Shantou City.Our factory located in Shenzhen.

Q: Can I buy direct?
A: Yes,you can buy from Surplus Directly.

Q: Do you manufacture your products in house?
A: Most of our products are manufactured in-house at our factory.Some accessory items are not.

Q: Can I get the riser on my L-shaped aquaculture heater longer/shorter?
A: Yes.There is no price difference for making a heater with a middle riser,but there maybe a cost adder for a longer riser.

Q: What Third Party Approvals do your products carry(CE?)
A: Almost all of our products are CE compliant.

Q: How late can you ship?
A: Normally 7 days after comfirmed the order.
